Liquid Oxygen Nitrogen Plants

Product Description

Since our inception year 1985, our company has been betrothed to manufacture, export and supply Liquid Oxygen Nitrogen Plants. The offered plants are designed for the fractional distillation of air to produce oxygen as well as nitrogen gas for variegated applications. These plants are assembled by our seasoned professionals using utmost quality components and advanced techniques in adherence with international quality standards. As per the specific needs of clients, these Liquid Oxygen Nitrogen Plants are available with us in various technical specifications at market leading prices. These plants operate by compressing the atmospheric using centrifugal type compressor at a pressure around 5-7 bar. Then, the compressed air is passed through pre cooling system to lower down the temperature below 12 deg C for the further processing into the purifier for efficiently extracting the impurities present as moisture, hydrocarbon and carbon dioxide with the aid of molecular sieves. After this, the gaseous mixture is further passed through the cryogenic refrigeration chamber for the efficient cooling for liquification at the temperature below -165 to-170 deg C. Moreover, these plants are equipped with air separation column for the safe separation of oxygen and nitrogen in different chambers with a purity of 99.6% and 99.9% respectively. Furthermore, the oxygen and nitrogen gas can be filled at 150 bar or higher pressures in the desired containers.

Features:

• Simple, ergonomic, pre-plumbed and stable structured plants

• Well-suited for conscious and unattended operations due to fully automated system

• User-friendly panel for ease in settling the parameters and operating plants

• Completely leakage-free systems for assuring safe production of gases

Types of plants :

• Large Capacity Plants (320 TPD TO 1600 TPD)

• Range 10,000 TO 50,000M3/hr.

• Purity oxygen -99.6% .Nitrogen -99.99% or 3PPM

• Operating Air Pressure- 0.6 TO 0.7Mpa

• Medium Capacity Plants(32 TPD TO 320 TPD)

• Range 1,000 TO 10,000M3/hr.

• Purity oxygen-99.6% .Nitrogen-99.99% or 3PPM

• Operating Air Pressure- 0.6 TO 0.7Mpa

• Small Capacity Plants

• Range 20 TO 800M3/hr.

• Purity oxygen -99.6% .Nitrogen -99.99% or 3PPM

• Operating Air Pressure- 0.6 TO 0.7Mpa






  Technical Specifications
  MODEL	PRODUCTION IN M3/HR	PRODUCTION LITERS/HOUR	PURITY
  UBPLN-50	50	73	99.99 To 99.99999%
  UBPLN-100	100	145	99.99 To 99.99999%
  UBPLN-200	200	218	99.99 To 99.99999%
  UBPLN-300	300	435	99.99 To 99.99999%
  UBPLN-400	400	578	99.99 To 99.99999%
  UBPLN-500	500	724	99.99 To 99.99999%
  UBPLN-1000	1000	1440	99.99 To 99.99999%
  UBPLN-1500	1500	2171	99.99 To 99.99999%
  UBPLN-2000	2000	2894	99.99 To 99.99999%
  UBPLN-3000	3000	4341	99.99 To 99.99999%
  UBPLN-4000	4000	5788	99.99 To 99.99999%
  UBPLN-5000	5000	7235	99.99 To 99.99999%
